Feature:

  • Mechanical linkage structure for lightweight operation
  • Designed for lifting workpieces with inner diameters 100~150mm
  •  Rubber-coated support surfaces to prevent workpiece damage
  •  Customizable per client requirements (e.g., diameters, load capacity)
  •  Surface treatments: Standard black oxide or optional nickel plating
Product Parameter

Item WLL Suitable Diameter Size（mm） Weight
kg mm A H kg
LB1-30 150 30 35 500 2
LB1-50 150 50 35 500 2.3
LB1-80 150 80 35 500 2.5
LB1-100 150 100 35 500 2.8
LB1-130 150 130 35 500 3
  LB1-150   150 150 35 500 3.2
  LB1-180   300 180 35 500 3.5
  LB1-200   300 200 35 500 4
   LB2-90    150 90 35 500 2.8
  LB2-120    150 120 35 500 3
  LB2-140    150 140 35 500 3.2
  LB3-150   300 150 35 500 3.3
  LB3-180    300 180 35 500 3.5
  LB3-200   300 200 35 500 3.7
  LB3-240   500 240 35 500 6
  LB3-280   500 280 35 500 6.2
  LB3-300   700 300 35 500 9
  LB3-350    700 350 35 500 10
  LB3-500    800 500 40 500 13
  LB3-800    1000 800 48 500 17
